Basic Information

• Nominal Voltage: 51.2V DC
• Voltage Range: 40V-58.4V
• Nominal Capacity: 100Ah
• Rated Capacity: 5.12kWh
• Max. Number of Parallel Connections: 32
• Cycle Life: 6000 cycles (25^oC@80% DOD)
• Protection Mechanism: Temperature Protection/Over-current Protection/Short-circuit Protection Over-charge Protection /Over-discharge Protection/Low-voltage Protection

Charging Parameters

• Recommended Charging Current: 50A
• Max. Charging Current: 100A
• Recommended Charging Voltage: 58V
• Max. Charging Voltage: 58.4V

Discharging Parameters

• Recommended Discharging Current: 50A
• Max. Discharging Current: 100A
• Recommended Battery Discharging Cut-off Voltage: 44V
• Battery Cut-off Voltage: 43.2V
• Battery Recovery Voltage: 48V

Product Functions

• Screen Type: Tauch Screen
• Communication: Bluetooth + Wifi
• Function: Auto-dialling communication

General Parameters

• Dimension: 640*380*160mm
• Protection Rating: IP20
• Net Weight: 45.3kg
• Shell Material: Sheet Metal
